Digital pH Meter Online with 4-20 MA output for PLC / Computer Scada Communication
Heavy-duty Industrial use, >1 Year Warranty.
Simple installation: large terminal compartment,
preassembled cabinet
Wall, post/pipe or panel mounting
Application in hazardous locations (FM Class Div 2)
Large, high-contrast display
Easy and intuitive operation
Optical alarm signaling by bright red LED
Temperature display either in °C or °F
Easy calibration with process mediu
2nd current output for temperature measurement
2 floating relay contacts
Sensocheck continuous sensor monitoring
Senso face preventive maintenance indication
Calimatric automatic buffer recognition
Measurement Range 0 to 14 pH
Accuracy ±0.02 pH
Resolution 0.01 pH
Response Time < 30 seconds (for 95% of final value)
Temperature Range 0°C to 100°C (depending on electrode type)
Pressure Range 0 to 6 bar (87 psi)
Temperature Compensation Automatic (with integrated Pt100 or Pt1000 RTD)
* Drinking water and wastewater monitoring
* Industrial process control
* Food and beverage production
* Aquaculture and agriculture
* Laboratory research and education
* Chemical and pharmaceutical industries
